Why Do We Bond at the Service Panel and Not a Subpanel?

Brendan Lamothe

Key Takeaways

  • Service panels require bonding between neutrals and grounds for safety.
  • Sub-panels keep neutrals and grounds separate to prevent objectionable current.
  • Proper setup is essential for safe electrical operations in your home.

Concept Of Service Panel Bonding

In a service panel, the neutrals and grounds are bonded together to ensure safety and functionality. All of the grounded and grounding conductors are connected at a single point to earth, preventing current from being on the grounding conductors during normal operation. This bonding ensures that in a ground fault situation—where a hot conductor potentially contacts metal components—there is a path for fault current to return to the source.

At the service panel, the bond allows fault current to safely travel back to the transformer, permitting the breaker to trip and indicating a fault. Without this bond, fault current would not complete a circuit, creating a potential shock hazard. By ensuring that the ground and neutral are bonded in the service panel, fault current can be directed precisely, preventing parallel paths and objectionable current.

In contrast, subpanels maintain separate neutral and ground conductors to avoid objectionable current. This separation ensures proper fault current flow in a clear path back to the service panel, preventing unsafe conditions where current might inadvertently split between the neutral and ground conductors.

Sub Panel Protocol

When working with sub panels, it's crucial to understand why you don't bond the neutral and ground at these locations, unlike the main service panel where bonding occurs. Bonding at the service panel ensures that all neutral and ground wires connect at a single point, which is crucial for safety and proper electrical operation. This setup ensures that any grounded conductor doesn't carry current under normal conditions but can carry fault current back to the main panel where the breaker can trip.

For a sub panel, maintaining a separation between neutrals and grounds is critical to prevent objectionable current. The neutral is a current-carrying conductor, while the ground is not intended for current flow except in fault conditions.

Key Points

  • Service Panel Bonding: Neutrals and grounds are bonded to ensure safe fault current paths.
  • Sub Panel Configuration: Neutrals and grounds should remain separate to avoid unwanted current paths.

Consider a scenario with a four-prong dryer plugged into a sub panel. The separation of neutral and ground ensures objectionable current doesn’t flow along unintended paths, like back through a ground wire. This setup minimizes potential hazards like electric shock.

By respecting these rules, you ensure safety and compliance with electrical codes, creating a reliable and effective electrical system in your home or workplace.

Objectible Current Explanation

When dealing with electrical systems, the concept of objectionable current arises. This term refers to situations where there is unintended current flow, creating potential hazards. Typically, objectionable current can occur in fault conditions when electrical paths allow current to flow where it should not.

Importance of Bonding

In a standard residential electrical setup, bonding occurs at the service panel. This is where the neutral and ground wires are connected to ensure safety. This bonding allows fault currents to have a direct path back to the transformer, facilitating the tripping of circuit breakers when a fault occurs.

  • Grounding Conductor: Should remain free from current during normal operation.
  • Neutral Conductor: Designed to carry current under normal conditions.

The Problem with Sub Panels

In sub panels, often found in locations such as a garage, you should avoid bonding the neutral and ground wires. This is due to the risk of parallel current paths forming, which can lead to objectionable current. This improper flow might cause equipment to malfunction or pose shock hazards to individuals.

Potential Risks

  • Parallel Paths: Current could travel via both neutral and ground wires, potentially bypassing the intended route.
  • Fault Conditions: Without proper bonding, faults may not complete the circuit needed to trip a breaker, allowing continued unwanted current.

By maintaining a single point of bonding at the main service panel, you ensure a controlled flow of electrical current throughout the system, which helps minimize the risks associated with objectionable current. This approach prioritizes both safety and functionality in electrical installations.

Fault Scenarios

The bonding of neutrals and grounds at the main service panel is crucial for safety. This connection ensures that all grounded conductors are tied together at one point, connected to the earth to prevent current on grounded elements. If a hot conductor becomes loose and contacts metal casing, the grounding conductor acts as a path to safely trip the breaker by providing a complete circuit back to the transformer.

Ground faults occur when a hot conductor contacts the equipment grounding conductor. This scenario must be distinguished from a short circuit, which involves direct contact between a hot conductor and either a neutral or another hot. Ground faults, unlike short circuits, necessitate that the grounding path effectively carries current caused by the fault back to the service panel, prompting the breaker to trip.

To prevent objectionable current, it is important not to bond neutrals and grounds in sub panels. Objectionable current is current where it shouldn't be, potentially flowing through both the neutral and ground, creating parallel paths. This undesirable scenario can lead to interference, equipment damage, or electrical hazards.

Maintaining the separation of these conductors at sub panels helps control precisely where fault current flows. Proper bonding at the service panel ensures the safe operation of electrical systems by allowing a clear path for fault current, triggering protection mechanisms and preventing hazardous conditions.

Panel Feeding Mechanics

At the service panel, all neutrals and grounds are bonded together, ensuring that the neutrals and grounding conductors connect at a single point. This bonding prevents current from flowing on conductive surfaces, especially during faults. If a ground fault occurs, the grounding conductor completes a circuit back to the transformer, allowing the breaker to trip.

In sub panels, such as those in garages, the bonding between neutrals and grounds is not done. Separation avoids objectionable current and minimizes parallel paths of current that could cause unsafe conditions. Neutrals carry current, while grounds should remain current-free under normal conditions. This separation ensures precise control over where current flows.

Fault scenarios illustrate this concept: if a hot conductor contacts a grounded surface, current flows back to the transformer through the grounding conductor if the neutrals and grounds are bonded at the main panel. This completes the circuit, trips the breaker, and prevents potential hazards. Without this bonding, the circuit remains incomplete, and current does not flow, posing significant risks.

Essentially, the bonding at the service panel maintains safety by directing fault current appropriately, while separation at sub panels prevents unintended current paths and ensures electrical systems function safely and efficiently.

Electrical Safety Measures

To ensure electrical safety, it's crucial to understand the reason behind bonding neutrals and grounds at the service panel, and why this is not done at sub panels. At the service panel, all neutral (grounded) and ground (grounding) conductors are combined at a single point that is connected to the earth. This setup prevents current from appearing on any ground conductors during normal operation, ensuring safety during a ground fault.

In typical scenarios, sub panels receive power from the main service panel through a dedicated breaker. The system includes an equipment grounding conductor and a neutral conductor. Equipment like modern four-prong dryers uses both, providing a stable flow of electrical current.

Key reasons for not bonding neutrals and grounds at sub panels include:

  • Objectionable Current Prevention: Objectionable current occurs when there is unwanted current in circuit paths where it should not exist. By keeping neutrals and grounds separate in sub panels, you avoid scenarios where both conductors unintentionally carry current, which could lead to hazardous conditions.
  • Fault Path Control: During a ground fault, such as when a hot conductor contacts grounded metal, having a bonded neutral and ground at the service panel ensures there is a clear path for fault current to return to the source. This path allows the breaker to trip effectively, reducing risk of electric shock or equipment damage.

By understanding these measures, you maintain a safe and efficient electrical system in your home. Always ensure that electrical work is performed per code requirements to maximize safety and functionality.
